Hats audit result
— Audit result, Sherlock — 10 min read
Hats is a protocol that can be used to organise roles of a DAO, their rights, and responsibilities. Hats are represented by a non-transferable ERC1155 token, wearers of a hat have a positive balance. Hats are organised in a hierarchy, higher hats have admin rights to hats below them.
The code was reviewed as part of the Sherlock contest. I ranked 3rd out of 152 participants in this audit. I found 3 high and 5 medium vulnerabilities, including one solo medium. I present my findings here.
High: Increase the number of valid signers past maxSigners
Summary
The number of valid signers can be increased past maxSigners if users are added, their hats are toggled of so they are considered invalid signers, new signers are added reaching the maxSigners limit, and the hats of the previously inactive signers are toggled back on.
Vulnerability Detail
reconcileSignerCount() does not remove inactive owners from the underlying safe, it simply updates the threshold and the signerCount value.
New users can be added with respect to the maxSigners constraint after signers have been made invalid by toggling their hats off and calling reconcileSignerCount().
Once the hats of the inactive users are turned back on, the number of valid signers on the underlying safe will go above maxSigners and checks like if (currentSignerCount >= maxSigs) { revert ... } will revert.
Impact
The number of signers on the underlying safe may go above limits resulting in failing safe transaction / reconcileSignerCount() due to maxSigs checks.
Code Snippet
High: Move tree root to different tree without consent
Summary
A tree root can be moved to a tree not within its current sub-tree without its explicit consent due to unfortunate ordering of actions.
Vulnerability Detail
If a topHat A is grafted onto a tree with admin B, requestLinkTopHatToTree() can be called by B to request A be linked to a totally separate tree via admin C.
B or C cannot immediately accept the link request to of A to C since _linkTopHatToTree() the function that executes the link checks that if A is already linked, C must be in the same tree as B.
However, if B calls unlinkTopHatFromTree() to be removed from the tree of B, C can immediately call approveLinkTopHatToTree() to link A to C.
Impact
If a hat calls unlinkTopHatFromTree(), to remove one of its branch, other branch admins can sandwich the call with requestLinkTopHatToTree() and approveLinkTopHatToTree() to link it back to itself or to another tree with the help of another tree admin.
Note that this is described under the assumption that unlinkTopHatFromTree() is called by admins of A which is untrue to docs but is the case in the code as I'll describe in another issue. The issue is still relevant ifunlinkTopHatFromTree() can only be called by A.
Code Snippet
No check of cross tree grafting in requestLinkTopHatToTree:
Check of cross tree grafting is done here:
Recommendation
Delete pending requests when ungrafting.
1function unlinkTopHatFromTree(uint32 _topHatDomain) external {2 uint256 fullTopHatId = uint256(_topHatDomain) << 224; // (256 - TOPHAT_ADDRESS_SPACE);3 _checkAdmin(fullTopHatId);45 delete linkedTreeAdmins[_topHatDomain];6+ delete linkedTreeRequests[_topHatDomain];7 emit TopHatLinked(_topHatDomain, 0);8 }High: checkAfterExecution threshold constraints incorrect
Summary
The goal of checkAfterExecution() is to "prevent safe signers from removing this contract guard, changing any modules, or changing the threshold". However the way it is enforces allow for changing of threshold under certain situations and prevents certain transactions to be executed in a restrictive manner.
Vulnerability Detail
The check enforces: if (safe.getThreshold() != _getCorrectThreshold()) { revert ... }. Which means the safe user could have changed the safe's threshold to the value returned by _getCorrectThreshold() after execution and the transaction would not revert.
However, I believe the most note-worthy behaviour is that the safe cannot impact the value returned by _getCorrectThreshold() without updating its internal threshold otherwise their transaction will revert.
Impact
A multisig safe owned by a DAO will not be able to slash one of its owner for misbehaviour using the multisig because this will result in the previously valid user losing its hat, thus lowering the value of _countValidSigners(safe.owners) returned by _getCorrectThreshold() under certain threshold assumptions, making the checkAfterExecution() call revert.
Code Snippet
Check on safe / HSG threshold:
Recommendation
Store the value of the underlying safe threshold locally in the before hook checkTransaction() and compare it in the after hook checkAfterExecution() if you want to enforce the safe's threshold does not change.
Solo Medium: Usage of HSG for existing safe can brick safe
Summary
The HatsSignerGateFactory allows for deployment of HSG / MHSG for existing safes. I believe the intention is to let the user call enableModule() and setGuard() on the safe after deployme with the HSG / MHSG address.
This can result in unmatching values of maxSigners in the HSG and number of valid signers of the safe. That will prevent further interaction with the safe rendering it unusable.
Vulnerability Detail
If a safe has 10 owners with valid hats, and a HSG / MHSG is deployed with a value of maxSigners < 10 and this HSG / MHSG is wired to the safe, the checks for validSignerCount <= maxSigners will revert in the HSG.
These checks are present in reconcileSignerCount and claimSigner. However reconcileSignerCount is a core function that is called by checkTransaction(), the pre-flight check on the safe transaction.
Impact
The safe will not be able to execute any transaction until the number of valid signers is lowered (some hat wearers give up their hats / some hats turns invalid ...)
Code Snippet
reconcileSignerCount checks maxSigners value:
It is called during checkTransaction:
The value is set once during setup and not changeable:
Recommendation
Allow this value to be changed by owner, or have a function that checks the HSG is safe before making it active after it is wired to an existing safe.
Medium: Prevent deployment of HSG when safe has more than 5 modules
Summary
I could not figure out why it is unsafe to use a gnosis safe with more than 5 enabled modules (as described in the code), but the current proxy factory will produce a HSG with wrong enabledModuleCount when we attempt to deploy a new HSG with an existing safe with more than 5 modules.
Vulnerability Detail
If the protocol considers it unsafe to have a safe with a guard HSG with more than 5 pre-existing modules, it should restrain it. In the current implementation, it is not restrained and result in a wrong value of enabledModuleCount.
Impact
HSG with wrong value of enabledModuleCount / bricked safe contracts.
Code Snippet
deployHatsSignerGate only gets the existing modules with a limit of 5:
Reference of get getModulesPaginated:
This is used to set the value of enabledModuleCount in the HSG:
The problem is the same for deployment of MultiHatsSignerGate.
Recommendation
In the proxy factory, get the modules with a limit of 6 and revert if the 6th value is non-zero. Note that a user could still deploy the HSG with the correct enabledModuleCount, add a module to the safe, and then bind the HSG to the safe. For a definite fix you'd need to have to call a function on the HSG that checks the module count of the safe before it is active.
Medium: setTargetThreshold can set target below minThreshold
Summary
The setTargetThreshold() function can be used by owner to set the target threshold below minThreshold value, which is unexpected in the remainder of the contract.
Vulnerability Detail
The function setMinThreshold() calls _setMinThreshold() which revert if _minThreshold > targetThreshold. However setTargetThreshold() does not enforce such constraint and can result in a value of targetThreshold < minThreshold.
Impact
Before safe tx execution reconcileSignerCount() will set the safe thershold to targetThreshold if the number of valid signer count is above the threshold.
After safe tx execution checkAfterExecution() will call _getCorrectThreshold() which will return the value of minThreshold if the number of valid signers is below it (which can be the case if targetThreshold < minThreshold). The check if (safe.getThreshold() != _getCorrectThreshold()) { revert ... } will then revert the execution of the transaction.
Safe transactions will no longer be executable.
Code Snippet
setTargetThreshold does not check for minThreshold constraints:
Check on safe / HSG threshold:
Recommendation
Prevent the target threshold to be set lower than minThreshold.
Medium: Fail to set safe threshold to targetThreshold
Summary
There is no guarantee that the signerCount value of HSG is in sync with the number of valid owners of the safe when owner calls setTargetThreshold() to change the target threshold of the HSG. This will be the case if the owner does not call reconcileSignerCount() beforehand or during set up of HSG that is being wired to an underlying safe.
This means the function _setSafeThreshold() may not be called and the value of threshold on the underlying safe remains higher than targetThreshold on the HSG.
Vulnerability Detail
This problem is made worse by the behaviour of reconcileSignerCount() which does not update the safe threshold if validSignerCount > targetThreshold && safe.getThreshold() > targetThresold.
Impact
The value of threshold on the safe may remain higher than targetThreshold on the HSG for a long period of time and go unnoticed to users / owner. This may result in safe tx execution failing unexpectedly.
After safe tx execution checkAfterExecution() will call _getCorrectThreshold() which will return the value of targetThreshold if the number of valid signers is equal to or higher than targetThreshold. The check if (safe.getThreshold() != _getCorrectThreshold()) { revert ... } will then revert the execution of the transaction.
I believe the impact is high as this issue is likely to arise without being caught and create confusion to users when they try to execute their transaction.
Code Snippet
setTargetThreshold only sets the safe threshold if signerCount > 1:
reconcileSignerCount does not update the safe threshold if validSignerCount > targetThreshold && safe.getThreshold() > targetThresold:
Check on safe / HSG threshold:
Recommendation
Update the safe threshold under less strict conditions.
Medium: _guardEntries not protecting against re-entry
Summary
Safe users can forge a transaction to call checkTransaction() from within the safe, which will increase the value of _guardEntries by 1, rendering the underflow check in checkAfterExecution() useless.
Vulnerability Detail
The safe users can forge valid data and signatures for a valid safe transaction with currentNonce + 1, and use this data to make a valid safe transaction with currentNonce that executes this data.
The execution will go through checkTransaction() before execution, bumping _guardEntries to 1. It will then execute itself, entering checkTransaction() once again, bumping _guardEntries to 2.
After the transaction is executed, checkAfterExecution() will lower _guardEntries back to 1 and leave it at 1.
The transaction execution coming from the safe, the protective measure if (msg.sender != address(safe)) revert NotCalledFromSafe() is useless.
Impact
The _guardEntries value can be bumped to 1 by safe users. I am not sure why the protocol wants to prevent re-entry using this value on these functions, but if it is important to the protocol, it should know it does not work.
Code Snippet
checkTransaction bumps _guardEntries:
checkAfterExecution lowers _guardEntries expecting to catch re-entry by having underflow errors:
Recommendation
Check that the value of _guardEntries is 1 before lowering it and revert if it is not.
